LDO CNC AWD V2.4 KIT

Take your Voron build to the next level with the LDO AWD (All-Wheel Drive) Upgrade Kit, engineered for precision, speed, and mechanical symmetry. This CNC-grade AWD mod delivers enhanced motion control and torque distribution across all axes. All of this makes the kit ideal for high-speed printing and demanding mechanical setups.

 Key Features

•  Compatibility: Designed for Voron 2.4
•  All-Wheel Drive Motion: Replaces dual motor drive with quad-motor CoreXY for balanced torque
•  Motor Support: Compatible with LDO 42STH48 series and Kraken motors (≥35mm shaft)
•  CNC-Machined Components: Precision aluminium mounts and pulleys for long-term durability
•  GT3 Belt System: Supports 6mm and 9mm GATES GT3 open belts for optimal grip
•  Pre-Wired Harness: Includes pre-cut, pre-crimped cables for plug-and-play installation
•  Symmetrical Motion Geometry: Reduces backlash and improves layer consistency at high speeds

 Why Upgrade to AWD?

• Improved Load Distribution: Four motors share the mechanical load, reducing wear and improving reliability.
• Enhanced Print Quality: Smoother motion and reduced vibration lead to sharper details and better layer adhesion.
• Higher Acceleration: Ideal for input shaping and high-speed tuning, especially with Klipper firmware.
• Modular Design: Easily integrates with existing LDO kits and toolhead PCBs like the Nitehawk SB.

 Kit Content

• 4x CNC motor mounts
• 4x GT pulleys
• 4x motor extension cables (pre-crimped)
• Belt tensioning hardware
• Mounting screws and spacers
• Installation guide (digital)
